Field Name Description
Subnet Mask This field is only relevant if you set the Enable all addresses field to
No.
Enter the Subnet mask associated with the IP address or group of IP
addresses specified above.
User Name The current credentials for remote access are displayed.
Modify the credentials here. You must be connected via HTTPS (see
above).
The default username for the web interface is Admin and the default
password is 1234.
We strongly recommend that you change the default credentials the
first time you access the XT Endpoint remotely.
Password
3. From the web interface only, select Save.
4. To perform remote upgrades, enable remote downloads as described in Configuring Remote
Upgrade Settings on page 58.
Configuring Remote Upgrade Settings
About this task
In order to upgrade your Scopia XT Endpoint for IP Office from the web interface, remote upgrade must
be enabled. This procedure describes how to:
•
Enable/disable remote upgrades (it is enabled by default)
•
Limit access to specific computers in the network. By default, all computers in the network can
perform remote upgrades.
You can do this procedure from the endpoint itself or from the XT Endpoint web interface.
Before you begin
•
If configuring from the endpoint, you must first enable advanced configuration, as described in
Maintaining the XT Endpoint Locally from the Endpoint on page 66.
•
By default, remote management is enabled. If you changed this configuration, make sure that you
enable it as described in Enabling Remote Management on the Scopia XT Endpoint for IP Office
on page 56.
Procedure
1. Access the remote download settings, as follows:
•
From the endpoint's main menu, select Administrator Settings > Utilities > Remote
Access > Download.
•
From the XT Endpoint web interface, select Configure > Advanced > Utilities >
Remote Access > Download.
Installation Guide for Scopia XT5000 Endpoint with Embedded
Server for IP Office Version 3.2
Initial Configuration | 58
