Figure 33: Configuring remote management on XT Endpoint
2. Set the fields as described in Table 10: Configuring remote management on XT Endpoint on
page 57.
Table 10: Configuring remote management on XT Endpoint
Field Name Description
Web Management Configure whether to allow remote management via the web
interface, as follows:
•
Select Yes to enable remote management of the XT Endpoint
from its web interface.
•
Select No to disable remote management of the XT Endpoint
from its web interface.
HTTPS Configure your web security settings, as follows:
•
Select Yes to enable secure HTTPS connection to the web
when remotely managing the XT Endpoint from its web
interface.
•
Select No to disable secure HTTPS connection to the web. For
example, if you remotely configure your endpoint only from
within your network, it may not be necessary to use HTTPS.
Enable all
addresses
Allow access to remote management for all or specific PCs, as
follows:
•
Select Yes to enable access to XT Endpoint from any IP
address in a network.
•
Select No to allow access to specified computers only. If
selected, you must also configure the Address and SubNet
mask as described below.
Address This field is only relevant if you set the Enable all addresses field to
No.
Enter the IP address or IP addresses of the computers allowed to
access XT Endpoint.
Installation Guide for Scopia XT5000 Endpoint with Embedded
Server for IP Office Version 3.2
Initial Configuration | 57
