Name Resolution
WXGA 1280x768/ 1280x800
720p 1280x720
XGA 1024x768
SVGA 800x600
VGA 640x480
3. Select Apply.
4. Select the refresh frequency rate from the Screen refresh rate field. See Table 9: Resolution
and refresh rates on page 32 for the supported resolution and refresh rates.
Table 9: Resolution and refresh rates
Name Resolution Digital Refresh Rate (Hz)
Analog Refresh Rate Frequency
(Hz)
1080p 1920x1080 60 60
SXGA 1280x1024 60,75 60, 75
HD+
(900p)
1600x900 60 N/A
WSGA 1440x900 60 60
UVGA 1280x960 60, 85 60, 85
WXGA 1280x768 /
1280x800
60 60
720p 1280x720 60 60
XGA 1024x768 60, 70, 75 60, 70, 75
SVGA 800x600 60, 72, 75 60, 72, 75
VGA 640x480 72, 75 72, 75
5. Select Apply.
Connecting Audio Equipment to the Scopia XT Endpoint for
IP Office
These sections describe how to connect audio equipment, such as a microphone, to the XT Codec Unit:
Navigation
•
Deciding on the Audio Setup for the Scopia XT Endpoint for IP Office on page 33
•
Connecting the Three-Way Microphone Pod on page 35
•
Connecting the One-Way Microphone Pod and other Analog Microphones on page 36
•
Connecting an Analog Sound System on page 38
