Installation guide

Chapter 5 | Setting up the Scopia XT
Endpoint for IP Office
After reading the section Prerequisites for Setting up the System on page 25, you can install the Scopia XT Endpoint
for IP Office. These sections describe how to install the XT Codec Unit and connect its accessories:
Navigation
•
Mounting the XT Codec Unit on page 28
•
Connecting Scopia XT Endpoint for IP Office to Your Network on page 28
•
Connecting a Computer to the Scopia XT Endpoint for IP Office on page 29
•
Selecting the Computer Display Resolution on page 31
•
Connecting Audio Equipment to the Scopia XT Endpoint for IP Office on page 32
•
Connecting the Video Equipment to the Scopia XT Endpoint for IP Office on page 40
•
Installing the Batteries of the XT Remote Control Unit on page 52
Mounting the XT Codec Unit
About this task
Follow the guidelines in this section to correctly place the XT Codec Unit.
Procedure
Place the XT Codec Unit following these guidelines:
•
Place the XT Codec Unit on a horizontal surface which stands firmly on its base.
•
The surface must be dry and free of dust, oil and other residues.
•
Leave enough space for air circulation and for connecting cables easily.
•
Place the XT Codec Unit anywhere within 5 meter reach of the camera cables.
Caution:
Do not place the camera on top of the XT Codec Unit. It can cause the system to overheat.
Installation Guide for Scopia XT5000 Endpoint with Embedded
Server for IP Office Version 3.2
Setting up the Scopia XT Endpoint for IP Office | 28
