Table 7: Outbound Ports to Open from the Scopia XT Endpoint for IP Office
Port Range Protocol Destination Functionality
Result of Blocking
Port
Required
162 SNMP (UDP) An SNMP
manager station
Enables discovering
the system IP address
via SNMP
You cannot discover the
system IP address via
SNMP
Optional
1718 H.225.0/ RAS
(UDP)
Multicast IP
address
224.0.1.41 (all
gatekeepers)
Enables H.323
endpoints to
automatically identify
the gatekeeper to
register with
H.323 endpoints can
only register with a
predefined gatekeeper
Optional
(recommended
if using a
gatekeeper)
3339, 3340 XML HINTS
(TCP)
Scopia Control,
Scopia XT
Desktop Server
Enables receiving
system status alerts
Cannot send system
status alerts; Scopia
Control and Scopia XT
Desktop Server cannot
function.
Optional
Configuring the TCP or UDP Port Range on the Scopia XT
Endpoint for IP Office
About this task
You can configure the TCP or UDP port range by setting the base port, which is the lower end of the port
range (if, for example, port 3230 is busy).
The Scopia XT Endpoint for IP Office uses dynamic TCP ports 3230-3248 for the following:
•
H.225.0: An H.323 protocol that specifies the messages and procedures used by gatekeepers to
set up calls.
•
Q.931:A telephony protocol used for establishing and terminating the connection in H.323 calls.
•
H.245: A Control Protocol used for multimedia communication; enables transferring information
about the device capabilities, as well as opening/closing the logical channels that carry media
streams.
•
SIP: A signaling protocol used for creating, modifying, or terminating multimedia connections
between two or more participants.
The Scopia XT Endpoint for IP Office uses dynamic UDP ports 3230-3248 for enabling real-time H.323
and SIP media, including audio, video, and H.224/data (RTP), and media control (RTCP).
Before you begin
If configuring from the endpoint, you must first enable advanced configuration, as described in
Maintaining the XT Endpoint Locally from the Endpoint on page 66.
Procedure
1. Access the port settings as follows:
•
From the web interface, select Administrator Settings > Networks > Preferences >
Dynamic Ports.
