Port Range Protocol Destination Functionality
Result of Blocking
Port
Required
3338 XML
Commands
(TCP)
Scopia Control,
Scopia XT
Desktop Server
Enables communication
with Scopia Control and
Scopia XT Desktop Server
by sending commands and
receiving responses
Cannot
communicate with
Scopia Control
application or and
Scopia XT Desktop
Server
Optional
3478, 3479 STUN
(UDP)
STUN Server Enables endpoints to
automatically discover the
presence of a firewall or
NAT, and to determine
their public IP address.
Cannot
automatically
discover the
presence of a
firewall or NAT
(only manual
configuration
available)
Optional
5060 SIP (TCP) Avaya IP Office
and any SIP-
enabled video
network device
Enables SIP call signaling Cannot connect
SIP calls over TCP
Mandatory
5060 SIP (UDP) Avaya IP Office
and any SIP-
enabled video
network device
Enables SIP call signaling Cannot connect
SIP calls over UDP
Mandatory
5070 BFCP (TCP) Avaya IP Office
and any SIP-
enabled video
network device
Enables SIP video content
(presentation) signaling
No SIP video
content available
Mandatory
55003 AT
Commands
(TCP)
An external
controlling device
Enables you to remotely
manage the XT Endpoint
via API
Cannot send/
receive commands
Optional
55099 Software
Upgrade
(TCP)
XT Endpoint
Software Upgrade
application
Enables software upgrade Cannot upgrade
software
Recommended
60123 Telnet (TCP) Telnet server Enables remote
management via Telnet
No Telnet access Optional
