Option Description
Bottom
wizard as described in Adjusting the Image
Position on page 78.
Right
4. From the web interface only, select Save.
Resolving Camera Issues
Problem
I cannot see the camera’s output after setting up.
You can also check the camera's output remotely from the Scopia XT Endpoint for IP Office
web interface by selecting More Actions > Web Video:
Figure 96: Remotely monitoring your camera’s
Problem
I can see the camera’s output, but I cannot move the camera.
Solution
Change the video source to the correct camera, as described below.
1. Select Control Camera from the Main menu (or from the In-Call menu, during a call)
and press ok/menu.
2. Press ok/menu again.
Installation Guide for Scopia XT5000 Endpoint with Embedded
Server for IP Office Version 3.2
Troubleshooting the Scopia XT Endpoint for IP Office | 151
