Table 4: Video capabilities for participants hosted by Scopia XT Endpoint for IP Office
Maximum Resolution XT Endpoint
Displayed and transmitted resolution (max) 720p (can be upgraded to 1080p)
Resolution of single participant's video in layout
(max)
448p
Important:
The capabilities depend on the selected CP layout.
If the Scopia XT Endpoint for IP Office is used only as an MCU for hosting videoconferences, block the
audio and video input from this Scopia XT Endpoint for IP Office during the meeting. For details, see
Configuring Call Settings on page 123.
Planning the Topology of Scopia XT Endpoint for IP Office
with Scopia XT Desktop
Scopia XT Endpoint for IP Office enables you to locally host videoconferences using its built-in MCU,
and extends your videoconferences to participants joining from a computer (with Scopia XT Desktop
Client) or a mobile device (using Scopia Mobile).
For example, when you start a videoconference with the XT Endpoint hosting the call, you can add other
participants by asking them to connect via a web link to the Scopia XT Desktop Server, which would
automatically install and launch Scopia XT Desktop Client on their computers, or Scopia Mobile on their
mobile devices.
If you do not register to IP Office, you cannot host videoconferences or use the full functionality of the
system.
The main features of the Scopia XT Endpoint for IP Office include:
•
Remote users can easily connect to a meeting hosted by the built-in MCU on the XT Endpoint, by
connecting via the Scopia XT Desktop Server.
The deployment has very few components. You do not need additional hardware like an external
MCU, Scopia PathFinder for firewall traversal, or Scopia ECS Gatekeeper for routing calls.
•
The included Scopia XT Desktop provides built-in NAT and firewall traversal functionality, enabling
secure remote connections from Scopia Mobile and Scopia XT Desktop Clients.
The Scopia XT Endpoint for IP Office includes the following:
•
Full SMB9 - Advanced MCU level, with up to 9 participants:
–
One local and eight remote endpoints
Or
–
One local and seven mixed endpoints and PC clients
Figure 2: Scopia XT Endpoint for IP Office Deployment on page 16 shows a typical topology for the
Scopia XT Endpoint for IP Office solution. For more information, see the Solution Guide for Scopia
Solution.
