Before you begin
1. Ensure that you have the root certificate for the certificate authority that your organization uses. The
root certificate must be compatible with the Base-64 ASCII code, in either .pem or .cer format.
2. Ensure that you have the signed certificate from the CA for the XT Endpoint (see Generating a
Certificate Signing Request for XT Endpoint on page 132 for details on generating the CSR).
Procedure
1. Access the XT Endpoint web interface, as described in
Accessing XT Endpoint Web
Interface on page 55.
2. Select Administrator Settings > Utilities > Certificates.
3. Import the Certificate Authority (CA) root certificate as follows:
Figure 81: Uploading the CA root certificate
a. Select Choose File (next to Step 3) and browse to the CA root certificate you received
from the CA.
b. Select Upload.
4. Import the signed certificate you received from the CA, as follows:
Figure 82: Uploading the signed certificate
a. Select Choose File (next to Step 4) and browse to the signed certificate you received
from the CA.
b. Select Upload.
The certificate is validated and its details appear (Figure 83: Signed certificate from the CA
on page 136).
