Important:
You cannot remove the local LDAP server.
•
A remote XT Endpoint's built-in LDAP server
The contacts are read-only when browsing a remote XT Endpoint's LDAP server. You can define
more than one of these LDAP servers, where each requires only the IP address of the remote
endpoint and its LDAP password.
•
A third-party LDAP server, such as Microsoft Active Directory
The contacts of a third party LDAP are read-only from the endpoint. The LDAP tree must have the
following specific structure and naming conventions:
–
The Root DN must be defined. For example, dc=company, dc=com.
–
All users (inetOrgPerson entities) must be located under an organizational unit (ou) in the
LDAP tree. For example, ou=people.
–
All endpoints (commObject entities) must be listed under an organizational unit called
h323Identity if they are to work with H.323, and SIPIdentity if they are to work as SIP
endpoints.
Since the XT Endpoint works both as an H.323 and a SIP endpoint, all XT Endpoint
commObjects should be listed under both organizational units.
–
Each endpoint is represented by a commObject with its commUniqueId. Each
commObject contains the details of accessing this endpoint, and the user associated with it.
Define the following fields:
Table 35: commObject fields
Field Value Comments
objectClass commObject Use this exact value
objectClass h323Identity Use this exact value
commOwner uid=<x>,ou=people,dc=compan
y,dc=com
The user ID associated
with this endpoint
h323IdentityEndpointType Terminal Use this exact value for
H.323 endpoints only
h323IdentitytransportID <ip address>
At least one of these fields
must be defined for an
H.323 endpoint.
h323IdentitytransportDigits <E/164 dial number>
h323IdentitytransportNumber <H.323 alias>
h323Identityh323-ID <H.323 alias>
SIPIdentitySIPURI <URI address of SIP endpoint> SIP endpoints only.
–
Each user (inetOrgPerson entity) must have its commURI field pointing to the user's
endpoint (commObject ID).
For example:
ldap://123.456.789.012/ou=h323identity,dc=company,dc=com??sub?(com
mUniqueId=6)
Scopia XT5000 Endpoint for IP Office
where commUniqueId refers to the commObject ID
