Determining the Priority of Audio versus Video Quality
About this task
Quality of Service determines how your network handles IP packets sent to your system during a video
conference. For example, you can set a higher priority to audio packets, so that when there is an issue
with packet loss, audio quality is maintained over video.
Bandwidth and video quality settings also contribute to call quality. If you experience problems with call
quality, refer to the Troubleshooting the Scopia XT Endpoint for IP Office on page 143.
Before you begin
Consult with your network administrator for more information about configuring Quality of Service.
Important:
For detailed information on QoS based on TOS, refer to RFC-1439.
If configuring from the endpoint, you must first enable advanced configuration, as described in
Maintaining the XT Endpoint Locally from the Endpoint on page 66.
Procedure
1. Access the network settings as follows:
•
From the XT Endpoint web interface, select Administrator Settings > Networks >
Preferences > QoS.
•
From the endpoint's main menu, select Configure > Advanced > Networks >
Preferences > QoS.
