Field Name Setting
Speed Select the suitable Ethernet speed: 10, 100, or 1000 MBPs for
GLAN.
This field is read-only if you selected Automatic for Speed/Duplex
mode.
Duplex mode Select the data transmission mode that is defined for your network
router or switch, either duplex or half-duplex mode.
This field is read-only if you selected Automatic for Speed/Duplex
mode.
4. From the web interface only, select Save.
Enabling NAT and Firewall Traversal with Scopia XT Endpoint for IP Office
About this task
Scopia XT Endpoint for IP Office fully supports NAT and firewall traversal, enabling you to place the unit
behind a NAT router or firewall and connect with other endpoints seamlessly.
Perform this procedure to enable your Scopia XT Endpoint for IP Office to traverse NAT and firewall. For
an explanation about NAT and firewall approaches, as well as examples of deployments, see Planning
NAT and Firewall Traversal with Scopia XT Endpoint for IP Office on page 16.
Before you begin
If configuring from the endpoint, you must first enable advanced configuration, as described in
Maintaining the XT Endpoint Locally from the Endpoint on page 66.
Procedure
1. Access the network settings as follows:
•
From the XT Endpoint web interface, select Administrator Settings > Networks >
Preferences > NAT.
•
From the endpoint's main menu, select Configure > Advanced > Networks >
Preferences > NAT.
