Field Name Description
Gateway IP Address If the system gets its IP address automatically, this field indicates
the gateway IP address assigned to the system.
If you entered the system’s IP address manually, type the gateway
IP address.
DNS Server IP
Address
If the system gets its IP address automatically, this field indicates
the DNS server IP address assigned to the system.
If you entered the system’s IP address manually, type the DNS
server IP address.
6. From the web interface only, select Save.
7. If you secured your XT Endpoint using TLS certificates and you now modified the IP address,
you must generate the CSR again, as described in Generating a Certificate Signing Request
for XT Endpoint on page 132.
Configuring Network Connectivity
About this task
This procedure describes how to configure the GLAN1 and GLAN2 ports.
You may want to enable both GLAN1 and GLAN2, for example, to use one network connection for
control and another for videoconferences.
Before you begin
If configuring from the endpoint, you must first enable advanced configuration, as described in
Maintaining the XT Endpoint Locally from the Endpoint on page 66.
Procedure
1. Access the network settings as follows:
•
From the XT Endpoint web interface, select Administrator Settings > Networks.
•
From the endpoint's main menu, select Configure > Advanced > Networks.
2. Select Parameters under GLAN.
