2.5.9.4 Transmit Filter Specification
Value Parameter
1
Condition
Min Max
Unit
Pass Band 851.0125 869.9875 MHz
Pass Band Insertion
Loss
Referenced to a 50 ohm
impedance
2.0 dB
Pass Band Ripple Referenced to a 50 ohm
impedance
-0.5 +0.5 dB
Stop Band
Attenuation
Referenced to a 50 ohm
impedance
-60 dBc
Note 1: Unless otherwise stated, all values are referenced to the top of the rack.
Refer to Appendix E for filter curve.
2.5.9.5 Receive Filter Specifications
Value Parameter
1
Condition
Min Max
Unit
Pass Band 806.0125 824.9875 MHz
Pass Band Insertion
Loss
Referenced to a 50 ohm
impedance
1.0 dB
Pass Band Ripple Referenced to a 50 ohm
impedance
-0.5 +0.5 dB
Stop Band
Attenuation
Referenced to a 50 ohm
impedance
-60 dBc
Note 1: Unless otherwise stated, all values are referenced to the top of the rack.
Refer to Appendix E for filter curve.
