Specifications

The K-1705 Series entry phones provide a tough and
attractive handsfree phone for apartment, and resi-
dential door entry or applications requiring a vandal
resistant speaker phone. The K-1705 Series entry
phones are available in two attractive finishes:
“brushed stainless steel” and “oil rubbed bronze”.
When the “Call” button is pressed, the K-1705-3
returns dial tone. The keypad may then be used to
dial any number. If no Touch Tone is entered within 8
seconds, CPC is detected, a busy signal is detected,
or the programmable maximum call time has elapsed,
the K-1705-3 will automatically disconnect. Alternatively, the K-1705-3 may be disconnected by pressing the “Call” button
again. The K-1705-3 comes complete with a standard, flush mount, rough-in box. In addition, an optional VE-6x7 weather
resistant, surface mount box is available (see DOD# 424).
The K-1705-3-EWP shares all of the features of the K-1705-3 in addition to Enhanced Weather Protection (EWP) for outdoor
installations where the unit is exposed to precipitation or condensation. EWP products feature foam rubber gaskets and boots,
sealed connections, gel-filled butt connectors, as well as urethane or thermal plastic potted circuit boards with internally sealed,
field-adjustable trim pots and DIP switches for easy on-site programming. For more information, see DOD# 859.
• Built-in high resolution color video camera with wide viewing
angle, tilt/swivel adjustments and wide operating temperature
of -30°F to 150°F
• Audio and video transmission on one CAT5E cable (page 5)
• Vandal Resistant Features: 14 gauge louvered 316 stainless
steel faceplate with permanent laser etched graphics, stainless
steel speaker/mic screen, heavy duty metal keypad and “Call”
button, impact and scratch resistant camera lens and hex drive
mounting screws
• Weather Resistant Features: Marine grade 316 stainless
steel faceplate, screws and and push button switch. Switch
internally sealed per IP67. Mylar speaker. Self-draining mic
mount. Faceplate, mic and speaker gaskets. Sealed camera
lens. Potted camera circuit board. Stainless steel phone and
camera mounting hardware
• K-1705-3-EWP is designed to meet IP66 Ingress Protection
Rating (see DOD# 859 for more information)
• Available in 2 standard faceplate finishes: 316 brushed
stainless steel or oil rubbed bronze
• Yellow “in use” LED
• Telephone line powered
• Volume adjustments for microphone and speaker
• Advanced call progress detection: disconnects on busy
signal, return to dial tone, CPC, reorder tone, maximum call
time out and 40 second silence time out
• Selectable auto-answer feature and push button disconnect
• Zinc plated steel rough-in box with (2) 3/4” conduit knockouts
• Optional VE-6x7 Surface Mount Box available
• Selectable VOX switching speed
K-1705 Series
K-1705 Series
Video Entry Phones
with Keypads
July 1, 2014
P
P
r
r
a
a
c
c
t
t
i
i
c
c
e
e
T
T
E
E
L
L
E
E
C
C
O
O
M
M
S
S
O
O
L
L
U
U
T
T
I
I
O
O
N
N
S
S
F
F
O
O
R
R
T
T
H
H
E
E
2
2
1
1
S
S
T
T
C
C
E
E
N
N
T
T
U
U
R
R
Y
Y
TECHNICAL
TECHNICAL
F
F
e
e
a
a
t
t
u
u
r
r
e
e
s
s
P
P
h
h
o
o
n
n
e
e
.
.
.
.
.
.
7
7
1
1
5
5
.
.
3
3
8
8
6
6
.
.
8
8
8
8
6
6
1
1
Dimensions: Overall: 140mm x 165mm x 66mm (5.5” x 6.5” x
2.6”) , Rough-in box: 114mm x 140mm x 64mm (4.5” x 5.5” x 2.5”)
Shipping Weight: 1.6 kg (3.5 lbs)
Operating Temperature: -34°C to 65°C (-30°F to 150°F)
Connections: Standard model: (3) gel-filled butt connectors (3M
Scotchlok UR2) and 2-position terminal block, EWP model: (5)
gel-filled butt connectors (3M Scotchlok UR2)
(See page 2 for complete specifications)
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
A
A
p
p
p
p
l
l
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
• Apartment entry phone when used with the K-1900-3
Apartment Entry Dialer or C-4000 Apartment/Office Entry
Controller or C-3000 Apartment Entry Controller
• Use with a Viking C-500 to control 1 or 2 (expandable to 8)
K-1705’s and door/gate control on a single phone line
• Use with a Viking C-2000B to control 1 to 4 K-1705’s and
door/gate control on a single phone line
• Courtesy and customer assistance phone
• Automated teller (ATM) phone
• Security or emergency phone
• Hot-Line phone when used with the K-1900-5 Hot-Line
Dialer
Note: When installing a line powered phone on a low
voltage and/or low loop current phone system extension, a TBB-1B
Talk Battery Booster may be required (DOD# 630).
• Kiosk phone with (100 number speed dialing) when used
with the K-1900-9 Multi-Number Dialer
Vandal Resistant Handsfree Entry
Phones with Built-In Keypad
K-1705-3 “Brushed 316 Stainless
Steel” (similar to brushed nickel)
K-1705-3-BN “Oil Rubbed Bronze”
(satin dark brown powder paint
with fine copper metallic)
