Owner`s manual

11
MOUNTING THE
STEREO
Be sure you test all connections first,
then follow these steps to mount the
stereo.
1. Disconnect the cable from the
vehicle battery’s negative (
–
)
terminal.
2. Disconnect the wire harness and
the antenna.
3. Insert both of the supplied
removal keys into the slots at the
top left and right sides of the ste-
reo until the keys lock into place,
and slide the sleeve off of the
stereo.
4. While pressing down and hold-
ing the triangle holders on the
top of the stereo, remove the
removal keys from the slots.
5. Insert the sleeve into the dash.
Then secure the sleeve to the
dash by bending out the appro-
priate tabs with a screwdriver.
Bend out all the side tabs.
6. Reconnect the wire harness and
the antenna.
7. Slide the stereo into the sleeve
until it locks into place.
8. To further secure the stereo, use
the supplied hardware to attach
one end of the supplied metal
strap to the bolt on the back of
the stereo.
