User manual

6
The table below describes the connectors on the GXP-2000 phone:
EXT
Extension connection for extended keypad(will
be implemented in the future)
LAN/PoE
10/100 Switch LAN port for connecting to
Ethernet. Support PoE (802.3af). Draws power
from both spare line and signal line
PC 10/100 Switch port for connecting PC
POWER 5V power port
HEADSET 3.5mm Headset port
Wall Mount
GXP-2000 can be wall mounted. There are two wall mount holes on the
bottom of the GXP-2000 main body:
User can simply place the device against the wall with two holes placed to
the fixed hanger position on the wall.
Tab
Handset
Rest
Tab with
extension down
Tab with
extension up
To
p
Wall
Mount hole
Bottom Wall
Mount hole
