Disable Call
Waiting
Default is No.
Quick IP-call
mode
Please refer user manual chapter 4.4.4.
Lock keypad
update
If this parameter is set to “Yes”, the configuration updates via keypad
for Menu Item 7, 9, 12 are disabled.
Syslog Server
The IP address or URL of System log server. This feature is especially
useful for ITSP (Internet Telephone Service Provider)
Syslog Level
Select the ATA to report the log level. Default is NONE. The level is
one of DEBUG, INFO, WARNING or ERROR. Syslog messages are
sent based on the following events:
• product model/version on boot up (INFO level)
• NAT related info (INFO level)
• sent or received SIP message (DEBUG level)
• SIP message summary (INFO level)
• inbound and outbound calls (INFO level)
• registration status change (INFO level)
• negotiated codec (INFO level)
• Ethernet link up (INFO level)
• SLIC chip exception (WARNING and ERROR levels)
• memory exception (ERROR level)
The Syslog uses USER facility. In addition to standard Syslog payload,
it contains the following components:
GS_LOG: [device MAC address][error code] error message
Here is an example: May 19 02:40:38 192.168.1.14 GS_LOG:
[00:0b:82:00:a1:be][000] Ethernet link is up
Allow DHCP
Option 66 to
override server
DHCP Option 66 is used to identify a TFTP server when the 'sname'
field in the DHCP header has been used for DHCP options. If you
choose yes, GXP2000 will use the TFTP server resolved from DHCP,
instead of the one you specified in the "TFTP Server" option above.
Allow DHCP
Option 42 to
override NTP
server
DHCP Option 42 specifies a list of IP addresses for Network Time
Protocol (NTP) servers available to the client. If you choose yes,
GXP2000 will use the NTP servers resolved from DHCP, instead of
the one you specified in the "NTP Server" option above.
Four independent SIP accounts each has its own configuration page. Their
configurations are identical. The following is a screen shot of SIP Account 1 settings.
