Device Mode This parameter controls whether the device is working in
NAT router mode or Bridge mode. Need save the setting
and reboot the device before the setting start to work.
WAN side http access If set to “Yes”, user can access the configuration page
through the WAN port, instead of connecting PC and
GXP2000 through the “PC” port to do the configuration.
On the other hand, it exposes the GXP2000 to others, and
may cause some security issues for users. Default is No.
Reply to ICMP on WAN port If set to “Yes”, The GXP2000 will respond to the PING
command from other computers for testing, but it also is
vulnerable to the DOS attack. Default is No.
Cloned WAN MAC Addr Allow the user to set a specific MAC address. Set in Hex
format.
LAN Subnet Mask Sets the LAN subnet mask. Default value is 255.255.255.0
LAN DHCP Base IP Base IP for the LAN port, which function as a Gateway for
the subnet.
Default value is 192.168.2.1.
DHCP IP Lease Time Value is set in units of hours. Default value is 120hr (5
Days.) The time IP address is assigned to the LAN clients.
DMZ IP Forward all WAN IP traffic to a specific IP address if no
matching port is used by HandyTone-486 itself or in the
defined port forwarding.
Port Forwarding Allow the user to forward a matching (TCP/UDP) port to a
specific LAN IP address with a specific (TCP/UDP) port.
Allow DHCP Option 2 to
override Time Zone setting
DHCP Option 2 specifies the offset of the client's subnet in
seconds from Coordinated Universal Time (UTC). The
offset is expressed as a two's complement 32-bit integer. A
positive offset indicates a location east of the zero meridian
and a negative offset indicates a location west of the zero
meridian. If you choose
y
es, GXP2000 will use the time
offset resolved from DHCP, instead of the one
y
ou specified
in the "Time Zone" option above.
In addition to the Basic Settings configuration page, end user also has access to the
device Status page. The following is a screen shot of the device Status page. Details are
explained next.
