The Parameters section allows to enable different features:
∞ 4FSK modem: enables the 4FSK modem performed by the DSP,
∞ Receiving as terminal: if checked, the Base Station receives as it were a terminal, without the repeater
features,
∞ Transmission as Base Station: if not checked, the Base Station transmits as it were a terminal, without
the repeater features,
∞ Enabling DMR repeater: enables the repeater features.
Hang time is the time that elapses after the killing of communication to the state of hibernation of the
base station. During this time if the terminal accesses the network it does not need to perform the de-
hibernation procedure and acquisition of synchronization, but can simply access the network. After this time a
terminal, to access the network, must “wake up” the base station by the hibernation state and acquire the
synchronization.
Hold time is the time the TX remains on air after the PTT release.
The Signalling section displays radio activities on the two timeslots and also some measures about the
quality of the radio channel.
6.2.2.12 DMR OPERATING MODES
This form allows the user to enable the radio network in simulcast or multisite mode.
In the section Base Station parameters you must specify the role of the Base Station (Master or
Satellite), the voting delay (it is the time that elapses from the current timeslot to the time of arrival of the
