This form allows the user to control and modify the subaudio and superaudio parameters.
You can set the frequency of the TCS tone (both TX and RX) or choose a DPL code (in the octal range 001-777),
which is expressed in octal notation.
To enable these functions click on Set ; All the parameters will assume their original values if you restart the
device, unless you perform a Save in eep operation (see the DMR LAYER CONFIGURATION paragraph).
6.2.2.10 ANALOG VOTER
Clicking on RA-DMR  RadioConfiguration  Analogical voter the following form will appear:
