HP filter
It is a programmable high pass filter that can be inserted at the output of the receiver. It is
used to eliminate the received subaudio.
LP filter
It is a programmable low pass filter that can be inserted at the output of the receiver. It is
rarely used to narrow the bandwidth of the receiver.
Delay
Allows you to set a delay on the received signal.
Its function is organized as follow:
1. Off: the filter is not active.
2. On: the filter is active, with minimum delay 1.938ms.
Set: the delay is selectable in the range 0 a 127ms (+1.938ms minimum delay), step 4 s.
