Menu item
Description
Operating modes
Radio operating mode
No configured Radio
No options selected
Subscriber point-point
Telephone point to point radio link, subscriber side
User point to point
Telephone point to point radio link, user side
2/4 wires point to point
Point to point radio link, 2/4 wires
Duplex repeater
Repeater
Satellite link side
RF link in a satellite, iso-frequency network
Satellite local transmitter side
Local transmitter in a satellite, iso-frequency network
Master
Master in iso-frequency networks
Master II
Sub master in iso-frequency network
ISO satellite 2/4 wires intermediate
Intermediate satellite in wire linked linear iso-frequency network
ISO terminal satellite 2/4 wires
Terminal satellite in wire linked linear iso-frequency network
Master ISO 2/4 wires
Master in wire linked linear iso-frequency network
Multiple RX master
Multiple receiver RF linked master
Line 0
Auxiliary line interface
Line 1
Auxiliary line interface
Line 2
Auxiliary line interface
Line 3
Auxiliary line interface
Special applications
Customized applications
Menu item
Description
Service
Communication service type
Simplex
Refers to a communication that occurs in one direction only.
Semiduplex
Refers to a communication that occurs in both directions, only one direction at time.
Duplex
Refers to a communication that occurs in both directions at the same time.
Menu item
Description
Type
Radio configuration
Available
Available to define
Normal
TRX of a Base Station configured as 1+1 (active)
Backup
TRX of a Base Station configured as 1+1 (hot spare)
Stand alone
Base Station configured as 1+0
6.2.2.2 CHANNELS TABLE
The channels table displays all the parameters associated with all channels set in the Base Station.
To open the channel table click on, Radio configuration  Channels table , as shown in the figure.
