User's Manual

Model and Ordering Information

This versatile WiFiHU2S family of products offers configuration options to meet the

specific system. The WiFiHU2S is available as a SMD module with antennas interface.

The WiFiHU2S also has many different antennas options.

*These models can use either one or two cables and antennas. For ultimate performance, we

recommend using two antennas with better adaptability for receiving. If user want to use

only one set of cable and Antenna, try to use CON1 first.

Model Description Comments

WiFiHU2S-a

WiFi SMD Module with dual on

board chip antennas

Uses onboard chip antennas.

Not for use with External

Antenna.

WiFiHU2S-c *

WiFi SMD Module with dual on

board U.FL connectors for

attaching antenna cables and

2.4GHz 2 dBi Omni-directional

antennas

Allows designer to determine

antenna placement. Can use

one or two cables and antennas

AC6i-RP-SMA

6" U.FL. to RP-SMA female

connector antenna cable

Antenna Cable for model

WiFiHU2S-c

ATN-2d-RP-SMA

Replacement antenna, 2.4GHz,

2dBi, RP-SMA, Omni-

directional.

Antenna for model

WiFiHU2S-c
