Applications
• Wireless keyboard and mouse
• Remote control
• Helicopter and airplane radio controller
• 2400 ~ 2483.5 MHz ISM system
• Wireless metering and building automation
• Wireless toys and game controllers
Features
• Small sizes: 0.57” x 0.99” x 0.12” (14.5mm x 25.2mm x 3.0mm)
• Frequency band: 2400 ~ 2483.5MHz.
• FSK or GFSK modulation
• Low current consumption: RX 16mA, TX 20mA (at 0dBm output power).
• Low sleep current (1.5 uA).
• On chip regulator, support input voltage 2.0 ~ 3.6 V.
• Programmable data rate from 2Kbps to 500Kbps.
• Programmable TX power level from – 20 dBm to 1 dBm.
• Ultra High sensitivity:
• -95dBm at 500Kbps on-air data rate
• -97dBm at 250Kbps on-air data rate
• -104dBm at 25Kbps on-air data rate
• -107dBm at 2Kbps on-air data rate
• Fast settling time (130 us) synthesizer for frequency hopping system.
• Built-in Battery Detector.
• Support low cost crystal (6 / 8 /12 / 16 / 20 / 24MHz).
• Support crystal sharing, (1 / 2 / 4 / 8MHz) to MCU.
• Support Frequency Compensation.
• Easy to use:
• Support 3-wire or 4-wire SPI interface
• ONE register setting for new channel frequency.
• 8-bits Digital RSSI for clear channel indication.
• Fast exchange mode during TRX role switching.
• Auto RSSI measurement.
• Auto Calibrations.
