Datasheet

10-19
Our Most Important Connection is with You.™
Go online for data sheets & assembly instructions. Visit www.radiall.com and enter the part number.
BNC 50Ω
RIGHT ANGLE PLUGS FULL CRIMP TYPE FOR FLEXIBLE CABLES
STRAIGHT JACKS FOR FLEXIBLE CABLES
Cable group
Cable group
dia.
Part number Fig.
Dimensions (mm)
Captive center
contact
Note
BC
5*5* 6 R141 181 161 1 3.25 1.7
yes
Commercial version
5*5* 6
R141 182 000 2 5.5 1.05 Single piece body
R141 182 161 1 5.5 3.15 Commercial version
R141 182 177
2
5.55 3.2 Non magnetic
5*5*5* ' R141 183 000 5.8 1.05 Single piece body
Cable group
Cable group
dia.
Part number Fig.
Dimensions (mm)
Captive center
contact
Note
AB
5*5*5*5*5* 6'
R141 207 000
1 5.6 1.05
no
Clamp type
R141 208 000
yes
5*5* 6 R141 217 000
2
0.57 Full crimp type
5*5* 6
R141 237 000
5.5 1.05
Single piece body,
full crimp type
R141 237 161
Commercial version,
full crimp type
5*5*5*
'
R141 220 000
Single piece body,
full crimp type
Fig. 1
Fig. 2
Fig. 1
Fig. 2
Right angle plugs and straight jacks
