TECHNICAL DATA SHEET
2/2
BULKHEAD JACK RECEPTACLE FRONT MOUNTING
R141.557.000
WITH SOLDER POT CONTACT
Series : BNC
Issue : 0431 E
In the effort to improve our products, we reserve the right to make changes judged to be
necessary.
PACKAGING SPECIFICATION
Standard Unit
O
ther
100 ‘W’ option Contact us
ELECTRICAL CHARACTERISTICS ENVIRONMENTAL
Impedance
50
Ω
O
perating temperature
-65/+165
°C
Frequency
0-4
GHz
H
ermetic seal
NA
Atm.cm3/s
VSWR
1.3
+
0.000
xF(
G
Hz) Maxi
P
anel leakage
NA
Insertion loss
.115*
√F(
G
Hz) dB Maxi
RF leakage - (
57
- F(GHz)) dB Maxi
Voltage rating
500
Veff Maxi
Dielectric withstanding voltage
1500
Veff mini
Insulation resistance
5000
MΩ mini
OTHERS CHARACTERISTICS
Assembly instruction
NA
O
thers
:
* Coaxial Transmission Line Only
MECHANICAL CHARACTERISTICS
Center contact retention
Axial force – Mating end
18
Nmini
Axial force – Opposite end
18
Nmini
Torque
2.8
N.cm mini
Recommended torque
Mating
NA
N.cm
Panel nut
250
N.cm
Mating life
500
Cycles mini
Weight
8.000
g
