TECHNICAL DATA SHEET
2 / 2
STRAIGHT JACK CLAMP TYPE
R141.207.000
CABLE 5/50 S+D Series : BNC
Issue : 0905 C
In the effort to improve our products, we reserve the right to make changes judged to
be necessary.
PACKAGING
Standard
Unit
Other
100
‘W’ option
Contact us
ELECTRICAL CHARACTERISTICS
Impedance
50
Ω
Frequency
0
-
4
GHz
VSWR
1.3
+
0,0000
x F(GHz) Maxi
Insertion loss
0.115
√F(GHz) dB Maxi
RF leakage
-
(
57
- F(GHz)) dB Maxi
Voltage rating
500
Veff Maxi
Dielectric withstanding voltage
1500
Veff mini
Insulation resistance
5000
M
Ω
mini
MECHANICAL CHARACTERISTICS
Center contact retention
Axial force
–
Mating end
NA
N mini
Axial force
–
Opposite end
NA
N mini
Torque
NA
N.cm min
i
Recommended torque
Mating
NA
N.cm
Panel nut
NA
N.cm
Clamp nut
450
N.cm
A/F clamp nut
11,0000
mm
Mating life
500
Cycles mini
Weight
16,7
000
g
ENVIRONMENTAL
Operating temperature
-
65/+165
° C
Hermetic seal
NA
Atm.cm3/s
Panel leakage
NA
SPECIFICATION
DHS 795 130
CABLE ASSEMBLY
Stripping
a b c d e f
mm
3,00 9,00 0,00 0,00 1,00 0,00
Assembly instruction : Clamp 02
Recommended cable(s)
KX 15
RG 141
KX 23
RG 142 FTX
RG 58
RG 142
RG 400
RG 223
Characteristics indicated on this data sheet are those that can be
achieved with the highest performance cable. Intrinsic limitations of
the cable may diminish the performance of the assembly
Cable retention
- pull off
180
N mini
- torque
NA
N.cm
TOOLING
Part
Number
Description Hexagon
. . .
OTHER CHARACTERISTICS
-
