BNC 75Ω
ELECTRICAL CHARACTERISTICS
Impedance
75Ω
Frequency range
'&*+]
V.S.W.R. max
straight models cable group: 2.6/75, 5/75, 6/75,
8/75, 10 + 11/75
right angle models: 2.6/75, 6/75
1.30
1.35
Insertion loss straight connector
right-angle connector
0,/
G%PD[DW*+]
G%PD[DW*+]
RF leakage
G%PLQIURPWR*+]
Insulation resistance
0řPLQ
Contact resistance center contact
outer contact
1.5 mΩ
0.2 mΩ
Working voltage in VRMS at sea level
(at 21 000m)
500
125
Dielectric withstanding voltage in VRMS
at sea level
(at 21 000m)
1500
375
RF testing voltage in VRMS sea level (5 MHz)
1000
MECHANICAL CHARACTERISTICS
Durability
0,/
500 matings
Force to engage and disengage axial
torque
13.6 N max
28.6 Ncm
Coupling nut retention force
445 N
Cable retention force cable 2.6/75, 5/75
6/75, 8/75, 10 + 11/75
340 N
Center contact retention force
27 N
ENVIRONMENTAL CHARACTERISTICS
4PbmPpCtupPpCcVPğP|XK`PLCK`Pq
0,/
-65°C + 165°C
Thermo cycling test
0,/67'PHWKRGFRQGLWLRQ%
High temperature endurance
0,/67'PHWKRG
Corrosion salt spray
0,/67'PHWKRGFRQGLWLRQ%
Vibration
0,/67'PHWKRGFRQGLWLRQ%
Shock
0,/67'PHWKRGFRQGLWLRQ*
Moisture resistance
0,/67'PHWKRG
Hermetic test
0,/67'PHWKRGFRQGLWLRQ&
vacuum 10
-6
+JPP7RUUOHDNDJHUDWH
-6
DWPFP
3
V
Barometric pressure
Pressure test: 3.5 bars; duration: 2 mn; temperature:
15°C to 25°C
MATERIALS AND PLATING
Materials Platings
Bodies Brass Nickel
Center contact male
female
Brass
%URQ]HRUKHDWWUHDWHGEHU\OOLXPIROORZLQJ44&
*ROG
Nut Brass
Insulator 37)(
*DVNHW Silicone Rubber
Test/characteristics
Standard
reference
Values/remarks
Standard packaging = 100 pieces.
Characteristics
