Chapter 3 Operation IPmux-16 Installation and Operation Manual
3-34 Configuring IPmux-16
Bundle Connection Configuration
Main Menu
↓
2. Configuration
↓
3. Bundle
Connection
Configuration
➤
To view and configure Bundle Connection parameters:
• Type 3 (Bundle Connection Configuration) in the Configuration menu.
BUNDLE CONNECTION CONFIGURATION
1. DS0 Bundle ID 1
2. Connection Status Enable
3. Destination IP Address 10.10.10.10
4. Next Hop 192.168.238.1
5. Destination Bundle 1
6. Jitter Buffer (x10 usec) 300
7. TDM bytes in frame 48
ESC. Exit D. Delete N. Next
SYSTEM USAGE: 6.25 %
Select item from the menu.
Use <ESC>-key or keys <1> to <7>
Figure 3-32. Bundle Connection Configuration
Parameters must be configured for each connection. To configure all parameters,
first select the bundle ID and then proceed with the parameter configuration.
➤
To set the source DS0 Bundle ID:
1. Type 1.
2. Type in the bundle ID: 1 to 496.
The bundle should be defined first.
➤
To set the Connection Status:
1. Type 2.
2. Use the <Spacebar> on your keyboard to toggle between Enable and
Disable.
When set to Disable, frames will not be sent on this connection.
➤
Destination IP Address
1. Type 3.
2. Enter the IP address of the destination device (IPmux-16).
Note
