Chapter 3 Operation IPmux-16 Installation and Operation Manual
3-20 Configuring IPmux-16
TFTP
Main Menu
↓
2. Configuration
↓
1. General Configuration
↓
4. Software
Download/Upload
↓
2. Download/Upload
TFTP
Enter 2 from the Software Download window to download or upload a file
by TFTP; the TFTP window is displayed.
DOWNLOAD\UPLOAD Using TFTP
1. File name “3V00.cmp”
2. Command
3. Server IP IP address
4. Retry timeout 15
5. Total timeout 60
6. User File Name XXXXXXXXX.YYY
7. View transfer status ¾
ESC. Exit S. Save & Start action
Figure 3-22. Download/Upload Using TFTP Window
➤
To download or upload a file by TFTP, do the following:
1. Enter 1 from the Download/Upload using TFTP window then type the
file name to be downloaded or uploaded.
2. Enter 2 and type the command to be executed on the file.
− SW download
− config download
− config upload
− LAN code download
Boot code download is not possible using TFTP.
3. Enter 3 and type the IP address of the server from which the file is
loaded.
4. Enter 4 and type in the desired retry timeout period (in seconds).
5. Enter 5 and type in the desired total timeout period (in seconds), which
is the maximum time allowed for attempted transmission.
Note
