- RAD Data Communications TDMoIP Gateway Installation and Operation Manual

IPmux-16 Installation and Operation Manual Chapter 3 Operation
Configuring IPmux-16 3-11
5. VLAN & IP Support Configure IP ToS and VLAN tagging
6. Configuration Summary View summary information of all existing
bundle connections.
CONFIGURATION
1. General Configuration
2. Physical Layer Configuration
3. Time Slots Configuration
4. Bundle Connection Configuration
5. VLAN & IP Support
6. Configuration Summary
ESC. Exit
Select item from the menu: _
Figure 3-10. Configuration Menu
General Configuration
Main Menu
↓
2. Configuration
↓
1. General
Configuration
➤
To display the General Configuration Menu.
• Type 1 (General Configuration) in the Configuration Menu, above.
GENERAL CONFIGURATION
1. Management Configuration >
2. ASCII Terminal Configuration >
3. Time/Date Update >
4. Download/Upload >
5. Set Default Parameters
6. File System >
ESC. Exit
Select item from the menu.
Figure 3-11. General Configuration Menu
Management Configuration
Main menu
↓
2. Configuration
↓
1. General Configuration
↓
1. Management
Configuration
Enter 1 from the General Configuration menu to access IPmux-16
management parameters; the Management Configuration menu will then
be displayed (Figure 3-12).
