Chapter 3 Operation IPmux-16 Installation and Operation Manual
3-8 Configuring System Parameters
SYSTEM
1.General Information
3.Reset
4.Event Log >
5.Ping
ESC. Exit
Select item from the menu.
Figure 3-5. System Menu
General Information
Main Menu
↓
1. System
↓
1. General
Information
➤
To display IPmux-16 general information:
• Type 3 (Event Log) in the System Menu.
• Type 1 (General Information) in the System Menu. This displays
information including software and hardware versions and module
descriptions. A typical General Information window for an IPmux-16 is
shown in the following figure.
GENERAL INFORMATION
Software Versions Hardware Version Inventory No.
Boot: 1.0 1-28-2001 17:16 0.2-C/1.1-A 133735
Application: beta 1.0
Modules Description Version Inventory No.
Network ETHERNET HW:4.0 SW:M.2 226833
User NO CARD N/A N/A
User 4E1 HW:2.0 184645
User NO CARD N/A N/A
Peripherals devices Present Status
Power supply1 Present OK
Power supply2 Present Failed
Fan1 Present Failed
Fan2 Present Failed
Press ESC to exit.
Figure 3-6. General Information Window
