Chapter 2 Installation IPmux-16 Installation and Operation Manual
2-2 Equipment Needed
The ambient operating temperature of IPmux-16 is 0
o
to 50
o
C
(32
o
F to 122
o
F), at a relative humidity of up to 90%, non-condensing.
2.3 Package Contents
The IPmux-16 package contains the following items:
• IPmux-16 unit
• Power cord
• CBL-DB9/DB9/NULL cross-cable that connects the IPmux-16 control port and
an ASCII terminal (DTE) for local management.
• RM-11 kit containing hardware for mounting IPmux-16 in a 19-inch rack
(optionally supplied).
Power Cable
IPmux-16 comes equipped with the power cord connected to PS1. If the unit is
equipped with a redundant power supply, IPmux-16 is equipped with an
additional power cord.
2.4 Equipment Needed
• Hand Tools and Kits
IPmux-16 needs no special tools for installation. A screwdriver is necessary
when mounting IPmux-16 in a 19-inch rack.
• Control Cable
IPmux-16 is provided with one null cable.
The null cable (CBL-DB9/DB9/NULL) is used to connect IPmux-16 (DTE) to a
terminal (DTE). Terminals are usually equipped with a male connector DB-9 or
DB-25; therefore the null cable should have a female connector.
A straight cable can be defined to connect IPmux-16 (DTE) to a modem (DCE).
