Publication No. 980935 Rev. M 3152B User Manual
Astronics Test Systems Programming Reference 5-19
Table 5-2, 3152B SCPI Command Summary (continued)
Keyword Parameter Form Default 3152A HS
Modulated Waveform Commands (continued)
[:SOURce]
:ASK
[:AMPLitude]
[:STARt] 0 to 16 5 0064A
:SHIFted 0 to 16 1 0065A
:BAUD 1 to 10e6 10e3 0066A
:MARKer 1 to 1000 1 0068A
:DATA <data_array> 00671#
:PSK
:PHASe
[:STARt] 0 to 360 0 0091A
:SHIFted 0 to 360 180 0092A
:RATE 1 to 10e6 10e3 0093A
:DATA <data_array> 00891#
:MARKer 1 to 4000 1 0090A
:FHOPping
:DWELl
:MODe FIXed | VARiable FIX 0069A
[:TIMe] 200e-9 to 20 200e-9 0070A
:FIXed
:DATA <data_array> 00711#
:VARiable
:DATA <data_array> 00731#
:MARKer 1 to 5000 1 0072A
:AHOPping
:DWELl
:MODe FIXed | VARiable FIX 0061A
[:TIMe] 200e-9 to 20 200e-9 0062A
:FIXed
:DATA <data_array> 00591#
:VARiable
:DATA <data_array> 00631#
:MARKer 1 to 5000 1 0060A
:3D
:DATA <data_array> 00521#
:MARKer 1 to 30000 0053A
:RASTer 1 to 2.5e6 1e6 0054A
