2.2 Sub Unit Overview
RSN-iDEN-30-DC is composed of the following sub units:
 UDC(Up Down Converter)
 HPAs(High Power Amplifiers)
 Multiplexers
 Main Control Unit (MCU)
 Power Supply Unit (PSU)
 EMI Filter
PSU
Multiplexer
MCU
UDC
DL HPA
EMI Filter
UL HPA
