2. Description
2.1 System Specifications
2.1.1 Electrical Specifications
Parameter Down Link Up Link
Operating Frequency 1930MHz~1995MHz 1850MHz~1915MHz
Gain 50dB to 90dB
Roll off ≤50dBc @Fedge+/-1MHz
Gain ripple ±1.5dB
Delay 5.0uS Max
VSWR 1.5Max
Rating(s)
Input: 110Vac ~ 125Vac, 60Hz, 2.0A
Output: +12Vdc or -12Vdc / Max. 2.0A
Operating temperature -10℃~ 45℃
Storage temperature -20℃~ 60℃
Band Selection
5MHz , 10MHz , 15MHz , 20MHz
5+5MHz , 10+5MHz , 15+5MHz , 20+5MHz
5+5+5MHz
