3.2 Mounting
CDMA MINI is easy to mount using the assembled mounting bracket, which has Ø9
holes for the provided 5/16" fixing screws.
Step 1.
B-TYPE : 152.4 [6.00] x 228.6 [9.00]
B-TYPE
A- TYPE
B-TYPE
A- TYPE
INSTALL RSN -C30-C
A-TYPE : 254 [10.00] x 228.6 [9.00]
Use this template to mark
the loca ti on for pilot holes
B-TYPE
A- TYPE
B-TYPE
A- TYPE
Step 2.
