STEP 5-SAFETY CABLE
A. Pass the cable through one hole on the Fastener first and then turn back to pass the cable through another hole on the Fastener. Make a
small loop that is just large enough for the Screw. Once the loop size is determined, thread the Set Screw into the Fastener and hand
tighten until snug.
B. Place the Spring Washer and the Flat Washer onto the Screw and pass the Screw through the Cable loop. Thread the Screw into the
ceiling, structural support close to the Hanger Frame. Hand tighten until snug to secure the cable.
: If you would like to install the cable to concrete ceiling, Wall Anchors will be required. Using a 5/16-inch drill bit (not included), drill
pilot holes at marked locations.
Note
