Installation Sheet

2of2

Thank you for purchasing a Quoizel product.

Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700

or visit us on-line at www.quoizel.com

2016 QuoizelInc.

PCSM1616C

FINISH: POLISHED CHROME

NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/4"

STEP 5 Install Glass to Fixture Body-

A. Insert Glass (C/D) into the Shade Holder (F) properly.

B. Place Shade Holder (F) over the side of the Fixture

Body (B), line up the hole on the Shade Holder (F)

and the mounting hole on the Fixture Body (B),

secure by threading Lock Screw (E) into the mounting

hole, tighten until sung.

Your fixture is now assembled and ready to use.

Enjoy!

8.75”

15.75”

4.5”
