Installation Guide

3 of 5
2020 Quoizel Inc.
visit us on-line at www.quoizel.com
STEP 4A
1 2
Step 1
Feed the fixture wires
through the loop
N
L
*Green Ground Screw
on crossbar optional
White wire (neutral)
from outlet box
Ground wire
from Fixture
Black or Red wire (hot)
from outlet box
Bare or Green ground wire
from outlet box
Supply wire from fixture
ribbed side or identified
with the Label “N”
supply wire from fixture
smooth side or identified
with the label “L”
STEP 5A
STEP 6A
