Installation Guide

ManualsBrandsQuoizel ManualsIndoor Ceiling FixturesBrockton 4 Light 18" Wide Semi-Flush Ceiling Fixture

1

2

3

4

Table Of Contents

2 of 5

2020 Quoizel Inc.

visit us on-line at www.quoizel.com

STEP 2A

1 2

3

Step 1

Install crossbar assembly

Step 2 - 3

Test fitting ceiling canopy to nipple

STEP 3A

2

Step 2 - 3

Install Fixture Chain

1

Step 1

Adjust fixture chain length

3

Suggested Chain Length:

8’ ceiling: 16” Chain

9’ ceiling: 28” Chain

10’ ceiling: 40” Chain

N

L

N

L

STEP 1A

Released Date: 2020-03-01

1 2

Remove lock ball

and knurled nut

Install fixture

loop assembly
