QuickJack Portable Car Jack 3 P/N 5900959 — Rev. H — May 2018
Table of Contents
Introduction 3 Setup 13
Shipping 5 Operation 28
Safety 5 Maintenance 38
Components 7 Troubleshooting 39
Accessories 9 Wiring Diagrams 41
Specifications 10 Labels 42
FAQ 12 Parts Sheets 47
Introduction
This manual covers all models of the QuickJack portable car jack, which makes Vehicle maintenance
in your garage or at the track fast and easy.
There are five QuickJack models:
• BL-3500SLX: Lifts Vehicles up to 3,500 lbs. on a frame of 62.5"
• BL-5000SLX: Lifts Vehicles up to 5,000 lbs. on a frame of 69"
• BL-7000SLX: Lifts Vehicles up to 7,000 lbs. on a frame of 69"
• BL-5000EXT: Lifts Vehicles up to 5,000 lbs. on an extended frame of 75"
• BL-7000EXT: Lifts Vehicles up to 7,000 lbs. on an extended frame of 76.25"
All models are CE certified. This manual is mandatory reading for all QuickJack users, including anyone
who sets it up, operates it, maintains it, or repairs it.
⚠ DANGER Be very careful when setting up, operating, maintaining, or repairing your unit;
failure to do so could result in property damage, product damage, injury, or (in very
rare cases) death. Make sure only authorized personnel operate the unit. All repairs
must be performed by an authorized technician. Do not make modifications to the
unit; this voids the warranty and increases the chances of injury or property
damage. Make sure to read and follow the instructions on the labels on the unit.
Keep this manual on or near your QuickJack so that anyone who uses or services it can read it.
Technical support for QuickJack is available directly from your distributor or you can visit
support.quickjack.com or email QuickJack Technical Support at [e-mail].
You can also request parts (be sure to have the serial and model numbers of your unit available).
