Instructions / Assembly

QuickJack Portable Car Jack 10 P/N 5900959 — Rev. H — May 2018
Specifications
Model
BL-3500SLX BL-5000SLX BL-7000SLX
Lifting capacity (per pair) 3,500 lbs / 1,588 kg 5,000 lbs / 2,268 kg 7,000 lbs / 3,175
A Collapsed height 3" / 76 mm 3" / 76 mm 3.9" / 99 mm
B Height, no blocks *
16.5" / 419 mm 17.6" / 447 mm 18.4" / 467 mm
C Height, small blocks 17" / 432 mm 18.4" / 467 mm 18.8" / 477 mm
D Height, tall blocks 18.5" / 470 mm 19.2" / 487 mm 19.6" / 497 mm
E Height, stacked blocks 20" / 508 mm 21.3" / 542 mm 21.7" / 552 mm
F Frame width 10.6" / 268 mm 11" / 278 mm 12.5" /318 mm
G Block position, max spread 50.5" /1,283 mm 60" / 1,524 mm 60" / 1,524 mm
H Block position, min spread 26.7" / 678 mm 29.5" / 749 mm 29.5" / 749 mm
I Frame length 62" / 1,575 mm 68.8" / 1,749 mm 68.8" / 1,747 mm
Individual frame weight 60 lbs / 27 kg 76 lbs / 35 kg 96 lbs / 44 kg
Power unit weight with carrier 35 lbs / 16 kg 35 lbs / 16 kg 35 lbs / 16 kg
Shipping weight 180 lbs / 81.64 kg 158 lbs / 71.66 198 lbs / 89.81 kg
Sound (when raising or
lowering)
<70 dBA <70 dBA <70 dBA
Maximum allowed wind
speed for safe operation
<60 mph (<96.5 kph) <60 mph (<96.5 kph) <60 mph (<96.5
kph)
* For reference purposes only; do not raise a Vehicle without Lift Blocks.
Specifications are subject to change without notice.
