FOLDING UP THE WATER-GATE FOR STORAGE
It is very important to fold each Water-Gate with aps laying at to ensure a long shelf life.
Folding the Water-Gate (model WL-1430 illustrated)
1 - After cleaning and drying the
Water-Gate, stretch it out on a
large at surface.
3 - Before folding the Water-Gate,
keep all the joints open to make it
easier to tie a second Water-Gate
to it, if need be.
2 - Make sure all inner aps are
facing the same direction & at.
A stick or pole may be used to
help atten.
4 - Start folding from the back
so that the ballast weights will
be positioned in the middle and
under the Water-Gate. Use the
folds already appearing on the
fabric as a reference.
5 - Depending on the model -
the unit may need to be ipped
over. If the instruction label is
visible, ip the unit & roll from
the opposite side of the label.
If the label is not visible- lift up
1 end to nd the label & then roll
from the opposite end.
6 - Once rolled, the velcro straps
will wrap around the unit & the
label will be visible.
Please note that the folding pattern and number of folds differ for each size of barrier
WL-06 and WL-14 Model
1 fold only
WL-20 and WL-26 Model
2 folds
WL-39 Model
3 folds
