User's Manual
Table Of Contents
- About the Document
- Contents
- Table Index
- Figure Index
- 1 Introduction
- 2 Product Concept
- 3 Application Interface
- 3.1. General Description
- 3.2. Pin Assignment
- 3.3. Pin Description
- 3.4. Operating Modes
- 3.5. Power Saving
- 3.6. Power Supply
- 3.7. Turn on and off Scenarios
- 3.8. Reset the Module
- 3.9. RTC Backup
- 3.10. UART Interface
- 3.11. USIM Card Interface
- 3.12. USB Interface
- 3.13. PCM and I2C Interface
- 3.14. ADC Function
- 3.15. Network Status Indication
- 3.16. Operating Status Indication
- 3.17. Behavior of the RI
- 4 GNSS Receiver
- 5 Antenna Interface
- 6 Electrical, Reliability and Radio Characteristics
- 7 Mechanical Dimensions
- 8 Storage and Manufacturing
- 9 Appendix A Reference
UMTS/HSPA Module Series
UC20 Hardware Design
UC20_Hardware_Design Confidential / Released 2 / 84
About the Document
History
Revision
Date
Author
Description
1.0
2013-07-17
Mountain ZHOU
Initial
1.1
2013-08-29
Mountain ZHOU
1. Updated USB driver information.
2. Added GNSS contents in Chapter 4.
3. Added GNSS current consumption.
4. Updated GNSS antenna requirements.
5. Released USIM_PRESENCE function.
1.2
2014-01-13
Mountain ZHOU
1. Added UC20-G information.
2. Added AMR-WB feature.
3. Added USB upgrade test points’ diagram.
4. Added reference design of transistor circuit on
UART interface.
5. Deleted debug function of Debug UART
interface.
6. Released AP_READY, UART upgrade
function and Rx-diversity function.
7. Modified UC20-A frequency bands.
8. Modified W_DISABLE# definition.
9. Modified USIM pin’s electrical characteristics.
10. Modified GNSS sensitivity definition.
11. Modified turning on timing figure.
12. Updated the sleep application in Chapter
3.5.1 and airplane mode in Chapter 3.5.2.
13. Updated I2C pins definition.
14. Updated current consumption.
