2.2. Buttons/Mini USB Interface Description
Button /Mini USB Interface Description
Power Key z Turn on GL100S
z Turn off GL100S. (If power key is enabled)
Mini USB interface z
Connect a 5V DC adapter can power
GL100S and charge the internal battery
z
Connect a 3.7V Li-ion or Li-Polymer
battery can power GL100S
z
Backend server developer or administrator
can use the Data_Cable to configure
GL100S
2.3. LEDs Description
There are three LED in GL100S, the description as following.
3. Getting Started
3.1. Parts List
Name Picture Remark
GL100S Locater
The GSM/GPRS/GPS locator.
Light Event State
NET light
Searching network
Fast flash
Network has been registered Slow flash
Power off Dark
PWR light Power on and normal Dark
Charger inserted and charging completed Solid
Charger inserted and charging Fast flash
Power key was pressed and prepare to power off Fast flash
Abnormal
Fast flash
Power low alert
Slow flash
Power off
Dark
