34
Menu F
unctions
Default:
ALL
[24:
SCN-CD] CTCSS/DCS Scanning
F
unction: Scans the incoming signal for CTCSS or DCS tones to identify or conrm
the correct tone. is function must be activated while receiving a signal.
Options: None. Choose the function and press [MENU] to activate the scan.
Note: e scan will stop when the signal ends and resume from where it left o the
next time the signal is received, until it identies the correct tone. Use the
[UP]/[DOWN] arrow keys to scan in a dierent direction. Use the [PF2]
side key to toggle between the standard CTCSS, positive DCS, and negative
DCS tone list.
N
ote
▪
U
se the [UP]/[DOWN] arrow keys to scan in a dierent direction.
▪
U
se the PF2 side key to toggle between CTCSS and DCS tone lists.
