32
Menu Functions
[19: S-TONE] Single Tone Pulse Transmission
Function: Activates the tone alert. Some relay systems used for single-tone pulse trans-
missions need a single-tone pulse signal to activate. To send the tone, press
the [PF1] side key while holding down [PTT].
Options: 1000Hz/1450Hz/1750Hz/2100Hz
Default: 1750Hz
[20: SC-QT] CTCSS/DCS Scan Save Options
Function: is item determines how a CTCSS or DCS tone is saved after a CTCSS/
DCS scan.
Options: R-CT/T-CT/RT-CT
Default: R-CT
R-CT: Saves the scanned tone to the RX-DTC setting
T-CT: Saves the scanned tone to the TX-DTC setting.
RT-CT: Saves the scanned tone to both.
[21: PONMSG] Power On Message
