29
Menu FunctionsMenu Functions
CTCSS, positive DCS, and negative DCS tone list.
Options: OFF/CTCSS/DCS+/DCS-
Default: OFF
[14: TX-DTC] Transmit CTCSS/DCS Tone
Function: Sets the transmitting CTCSS or DCS code for the selected channel. Use the
arrow keys to select your preferred code and then [MENU] to conrm. Once
the menu option is selected, use the [PF2] side key to toggle between the
standard CTCSS, positive DCS, and negative DCS tone list.
Options: OFF/CTCSS/DCS+/DCS-
Default: OFF
Note
▪
Use the PF2 side key to toggle between CTCSS and DCS tone lists.
▪
Non-standard CTCSS/DCS codes can be assigned using the PC programming
software.
